Looking to run full e85 or maximize performance of your 3.0L EcoBoost Ford Bronco Raptor or Ford Ranger Raptor? That's possible with a ZFGR Custom Tune and Fuel System Upgrade!
SAVE $100 WHEN YOU BUNDLE HPFP WITH INJECTORS
- Nostrum High Pressure Fuel Pump Upgrade Options:
- Standard HPFP - Recommended for performance-focused customers running e30-e50 on stock turbos, or for non-performance-focused customers looking to run full e85
- Goliath HPFP - "Future-proof" option; Only compatible with Stage 3 Injectors; Recommended for customers running e50+ on upgraded turbos, or for performance-focused customers looking to run full e85
- Injector Upgrade Options:
- Stage 1 - Recommended for non-performance-focused customers looking to run full e85
- Stage 2 - Recommended for performance-focused customers running e30-e50 on stock turbos
- Stage 3 - "Future-proof" option, compatible with Standard HPFP and Goliath HPFP; Recommended for performance-focused customers running e50+ on upgraded turbos, or for performance-focused customers looking to run full e85
* * TUNE with ECU swap required * * See our Stage 0 Package for Bronco Raptor / Stage 0 Package for Ranger Raptor
Standard HPFP Kit Includes:
3.0L Ford High Pressure Fuel Pump Kit
- H086-1953 High Pressure Fuel Pump Kit - fully welded stainless-steel construction
- Pump mounting flange with flange alignment tool
- Stainless-steel High-Pressure Tubes with OEM fittings for R-Code engine
- Electrical Connector Adapter harness
- Installation Guide
Standard HPFP Vehicle Application List:
2022+ Ford Bronco Raptor 3.0L
2024+ Ford Ranger Raptor 3.0L
Goliath HPFP Kit Includes:
- 1200-250 “Goliath” High Pressure Fuel Pump
- Pump mounting flange
- All new stainless-steel High-Pressure Tubes with OEM fittings
- AN06 to 3/8” SAE QD adapter fitting
- AN06 to ORB adapter fitting
- Plug and play wiring harness adapter
- Vibration damping sleeve w/ clips
- Installation Guide
- Warning cards
Goliath HPFP Vehicle application list:
2023-2024 Ranger Raptor
2023-2024 Bronco Raptor
R-Code 3.0 Ecoboost Engine
Item Category: Fuel System
Item Type: Injectors, Fuel Pump
Fuel Pumps, Injectors, HPFP, LPFP, Port Injection, Port Injectors, fuel rail, fuel pressure regulator, lift pump, Direct Injectors, Direct Injection
Manufacturer: Nostrum
Nostrum High Performance, Nostrum Fuel Systems, Nostrum Engineering
Part #:
Manufacturer's Product Description:
Recommended For
An upgraded fuel system supports use of higher ethanol content fuels than the stock fuel system. Since Ethanol (e85) contains more oxygen than pump gas, it results in a more efficient combustion process that produces additional power.
Ideal for:
High-performance applications, making maximum power
Customers looking to run full e85 on applicable platforms
Product Function & Benefits
Fuel Systems can vary drastically from one vehicle to the next. The specific recommendations and benefits will depend on your goals and the platform.
Basic Components of a Fuel System:
Fuel Pump(s): Deliver fuel from the fuel tank to the injectors.
Fuel Injectors: Sprays fuel into the intake ports (Port Injection) or combustion chambers (DI).
Fuel Pressure Regulator: Ensures that fuel pressure is maintained within the desired range.
Electronic Control Unit (ECU): Controls the timing and amount of fuel injected. (This is where tuning comes in!)
Tune-Related Impact & Tuner Recommendation
Recommended vs Required:
• In general, we recommend upgrading fuel system components for max effort builds, or for running ethanol content greater than the stock fuel system can support.
• Upgrading the fuel system is not required for tuning.
• Tune requirements are dependent on which part(s) you're upgrading and the fuel you're using.
• Upgraded injectors always require a tune.
• Upgraded fuel pumps may not require a tune, but having one is strongly recommended if it is not required.
• Upgrading the fuel system on a tuned vehicle requires a tune update.
• You may also need an Additional Tune to cover additional fuel types.
Explorer-Specific Information
Fuel System Setup: The 3.0L EcoBoost uses a two-pump fuel system in which an in-tank low-pressure fuel pump (LPFP) delivers fuel to a high-pressure fuel pump (HPFP). This setup is commonly referred to as a returnless fuel system. The HPFP, which is mechanically driven and mounted on the engine, then increases the fuel pressure to the levels required for direct fuel injection (also called direct injection or DI).
When to Upgrade / Stock Fuel System Capability:
The stock fuel system is capable of supporting up to 50% ethanol content (e50) with no other modifications. Upgrading turbos or running a higher ethanol content may require fuel system upgrades.
We do not recommend upgrading the fuel system for 3.0L vehicles running pump gas (87-93 octane). Otherwise, your specific goals and build plan will determine our recommendations.
Why not upgrade the fuel system for pump gas?
A 40%+ HPFP with 24% over injectors will max out the stock turbos, and would produce max power with an ethanol content of 40-50%. If the turbos have been upgraded, the same HPFP and injectors will produce max power with an ethanol content of 50-60%.
General recommendations for this platform are as follows:
HPFP:
Choose one that provides a flow rate at least 40% greater than stock.
For customers planning max effort builds, we recommend the greatest flowing HPFP available.
Injectors:
For versatility and fuel system efficiency, we recommend injectors that support a flow rate of at least 20% over stock.
For customers planning max effort builds, we recommend the largest injectors available (Nostrum Stage 3 = 96% over).
Additional Considerations:
As always, with great power comes great responsibility. Upgrading your fuel system has the potential to increase power output beyond what other components can support (e.g., transmission). Please be diligent in ensuring that you are adding sufficient support for each upgrade. We are here to help if you have any questions or would like specific recommendations.
F150-Specific Information
Fuel System Setup: The capability and point of requiring fuel system upgrades varies by engine. Your specific goals and build plan will determine our recommendations. Aside from the general information below, fuel system recommendations are made on a case-by-case basis.
When to Upgrade / Stock Fuel System Capability:
2.7L F150 (2018+ - Factory Port Injection)
Can run up to full e85 with a tune only. No fuel system upgrades are needed in most cases.
3.5L F150 (High Output - Raptor, Limited)
Can run up to e50 with no additional modifications. For customers looking to run full e85, a port injector upgrade is required.
We recommend injectors with a capacity of 1065.0 CC.
This upgrade is sufficient to support upgraded turbos running full e85.
3.5L F150 (Standard Output)
Can run up to e50 with no additional modifications. For customers looking to run full e85, a fuel pump and port injector upgrade is required.
We recommend upgrading to the OEM High-Output Pump (OEM Raptor Fuel Pump)
We recommend selecting injectors with a capacity of 1065.0 CC.
Additional Considerations: As always, with great power comes great responsibility. Upgrading your fuel system has the potential to increase power output beyond what other components can support (e.g., transmission). Please be diligent in ensuring that you are adding sufficient support for each upgrade. We are here to help if you have any questions or would like specific recommendations.
Vehicle Applications
Confirmed Fitment for 3.0L
Data / Results
Please Note: Data has been provided by the manufacturer, and may be supplemented by ZFG Racing.
